Picture Engraver
by lasertools.orgSettings
Default Engraving Settings
Material [DEV]
Frequency Range (kHz)
Lines/cm Range (LPC)
Standard Colors (Black & White)
Test Grid Calibration
Optimized Business Card Grid
The perfect starting point for stainless steel color engraving.
⚠️ .xcs: Manually raise the laser focus UP by 4 mm in xTool Studio before engraving.
✨ .xs (new): Defocus is embedded in the file — no manual focus adjustment needed.
- Format: 85mm × 55mm (Business Card)
- Density: 122 Test Points (14 × 9 Grid)
- Frequency: 40kHz - 90kHz (Optimized range)
- Lines/cm: 800 - 300 (High to Low)
- Passes: 1
- Smart QR: Located at bottom-right, scanned for auto-settings.
Create a custom calibration grid with your specific limits and dimensions.
⚠️ .xcs: Manually raise the laser focus UP by 4 mm in xTool Studio before engraving.
✨ .xs (new): Defocus is embedded in the file — no manual focus adjustment needed.
Axis Picker ⓘ
Build a grid from any two variables. Pick one X (columns) and one Y (rows); every other variable stays fixed at its • value. Axis variables show a min → max range; constant ones show a single value.
X columns
Y rows
• hold constant
Material [DEV]
Frequency (kHz) ⓘ
Lines/cm (LPC)
Parameters
Grid Layout
Options
Size: 14 × 9 cells
Points: 122
Upload a photo of your engraved test grid. The app will read the QR code to identify settings and map colors to laser parameters.
📷
Drop test grid photo here
or click to browse
🖱️
Click to Align Grid
Opens fullscreen view
Detected Settings
Upload a grid photo to analyze...
Can't read the QR code? You can use the default settings or enter them manually:
Grid Layout
Frequency (kHz)
Lines/cm
Step 2: Map Colors
Click a cell below to capture its color and see settings.
Selected Settings
40kHz / 800 LPC
💡 Tip: If the colors look wrong, try to click the 4 corners of the card in the image
above to re-align the grid.
Saving will store these calibrated colors for use with the Auto-Assign feature.
✅ Color map saved! You can now use Auto-Assign Colors when processing images.
Color Grids
Active grids are merged for Auto-Assign. Toggle to enable/disable.
Loading...
